TE12513C
The premier tedder experience is easily found in the Kubota TE12513C and its 43'11” working width makes haymaking efficient! The tedder’s Super-C tines spread the crop in an inverted fashion, meaning the lower crop is placed on top, providing you with an even dry down. Kubota’s commitment to durability is showcased in the tedder’s rotor gearbox and chassis, and with a transport width of just 9'8” you’ll swear the TE12513C is your new best friend.
TE12513C Specs & Compare
Specifications
| FarmLine | FarmLineN/A | |
|---|---|---|
| ProLine | ProLineStandard | |
| Working Width ft. (m) | Working Width ft. (m)36' 9 | |
| Width, Working Position ft. | Width, Working Position ft.43' 11 | |
| Transport Width ft. (m) | Transport Width ft. (m)9' 8 | |
| Transport Length ft. (m) | Transport Length ft. (m)22' 2 | |
| Storage Height ft. (m) | Storage Height ft. (m)9' 5 | |
| Weight lbs. (kg) | Weight lbs. (kg)8378 | |
| Capacity Theor. acres/h | Capacity Theor. acres/h10.7 | |
| Three-Point, Tracking | Three-Point, TrackingN/A | |
| Linkage Drawbar | Linkage DrawbarN/A | |
| Two-Point, Linkage Arms | Two-Point, Linkage ArmsN/A | |
| Vibration Damper/Integral Lock | Vibration Damper/Integral LockN/A | |
| Number of Rotors | Number of Rotors12 | |
| Number of Tine Arms/Rotors | Number of Tine Arms/Rotors6 | |
| Tine Adjustment System | Tine Adjustment SystemStandard | |
| Adjustment of Spreading Angle | Adjustment of Spreading AngleStandard | |
| Cab Contr. Border Clearing System, Mech. | Cab Contr. Border Clearing System, Mech.N/A | |
| Cab Contr. Border Clearing System, Hydr. | Cab Contr. Border Clearing System, Hydr.Standard | |
| Reduction Gearbox for Night Windrows | Reduction Gearbox for Night WindrowsOptional | |
| Wheels (4) | Wheels (4)16x6.5-8 | |
| Tires on Central Unit | Tires on Central Unit11.5/80-15.3 | |
| Front Wheel (16x6.50-8) | Front Wheel (16x6.50-8)N/A | |
| Tandem Axles | Tandem AxlesN/A | |
| Warning Panels | Warning PanelsN/A | |
| Warning Panels with Integr. Lighting | Warning Panels with Integr. LightingStandard |
TE12513C Features & Benefits
Low Maintenance Levels
The TE12513C and TE14515C tedders are crafted for low maintenance, allowing you to enjoy easy operation with extended service intervals. Spend less time on upkeep and more time on the field.
.jpg?sfvrsn=237c76c8_1)
Easy Compact Transport
Thanks to the trailed concept, transporting the TE12513C and TE14515C is straightforward and compact. Move effortlessly between fields with this convenient and efficient transport design.
Minimal Hydraulic Requirements
These tedders require only one single and double acting outlet, simplifying your hydraulic needs. This makes them versatile and easy to integrate with various tractors, streamlining your operation.
Multiple Rotor Options
Available with 12 or 14 rotors, these tedders provide outstanding crop turning in all conditions. Whether dealing with dense or light crops, the TE12513C and TE14515C deliver consistent, high-quality results.
Innovative TerraFlow Ground Following System
Equipped with the new TerraFlow ground following system, these tedders feature a highly flexible frame that ensures exceptional ground adaptation. This results in superior crop turning capabilities, enhancing your overall productivity.
High Headland Clearance Position
Benefit from a high headland clearance position, which offers excellent maneuverability and reduces crop damage during headland turns. This feature ensures smoother operation and better crop protection.
